Automated flash point - Pensky Martens

NPM 450

Ref. : 60400

ASTM D93

IP 34

ISO 2719

Temperature range 0°C to 410°C
3 methods (Methods A, B, C)
User programmable methods
Automatic gas flame relighting
Heavy sample preheating and automatic strirring start
Rapid cooling of heating block by air turbine

Supplied with :

Cup and lid
1 PT 100 probe
Detection thermocouple
Electric ignitor

Options and accessories

Ticket printer
Option: automatic nitrogen extinguisher

Security

Illuminated extinguisher push button
Gas flame detection
Over temperature protection
Built in gas leak detector

Software

Easy to use
Windows 8 operating system
Lifetime data storage – 32 GB SSD
Reporting: PDF, Excel, Word, Email, LIMS
Different access level settable (Operator – supervisor or maintenance…)

Site requirements

Power supply: AC 110/240V, 50/60Hz – 4A
Dimensions (mm): (W) 260 x (D) 460 x (H) 185
Weight: 12kg

Summary

ASTM D 93, an international test method for petroleum products and biodiesel

These test methods cover the determination of the flash point of petroleum products in a temperature range between 40°C and 370°C using a Pensky-Martens manual or automatic closed-cup apparatus, and the determination of the flash point of biodiesel in a temperature range between 60°C and 190°C using a Pensky-Martens automatic closed-cup apparatus.
